Cost-effetive with simple installation and stable performance, this optical two-stage tea grading machine can be applied to all kinds of tea leaf sorting.
Item NO.:
TCProduct Detail
AMD® Two-Stage Tea Grading Machine
The design of this double-layer intelligent tea grading machine includes 2 sorting boxes and can be configured with 2, 4 or 6 cameras/chutes if you want to increase the capacity. It can efficiently identify and separate tea stalks, defective objects and other non-tea impurities.
Technical Parameters
|
MODEL |
CAPACITY (KG/H) |
CARRYOVER RATIO (BAD:GOOD) |
ACCURACY (%) |
VOLTAGE/FREQUENCY (V/Hz) |
POWER (KW) |
AIR PRESSURE (Mpa) |
WEIGHT (KG) |
DIMENSION (mm) |
|
T2C2 |
250 |
>120:1 |
>99% |
220V/50Hz |
3.2 |
0.6-0.8 |
870 |
1310*1934*1984 |
|
T2C4 |
400 |
>120:1 |
>99% |
220V/50Hz |
4.6 |
0.6-0.8 |
1185 |
2289*2374*1982 |
|
T2C6 |
450 |
>120:1 |
>99% |
220V/50Hz |
5.3 |
0.6-0.8 |
1660 |
3340*2292*2684 |
Sorting Applications
Zhongke AMD is specialized in providing reliable sorting/grading machine and solutions for the tea processing industry. With 10 core technologies, AMD tea grading machine can intelligently sort all tea varieties such as black tea, green tea, dark tea, etc. according to the difference in tea color, size and shape.
Showcases of AMD Tea Sorting Machine
