The AMD® K2C6 Waste Glass Powder Color Sorting Machine delivers high-precision color separation of fine glass powder, enabling efficient impurity removal and improved material purity for high-value glass recycling applications.
Item NO.:
K2C6Product Detail
The K2C6 optical sorting machine is designed for the precise sorting of glass powder and key raw materials used in glass production, such as quartz sand. It efficiently processes materials within a wide particle size range of 16–140 mesh, ensuring stable quality and improved purity in fine material recycling and preparation.
Core Technologies
Wide particle size adaptability (16–140 mesh)
Ensures stable and accurate sorting performance across a broad range of glass powder and mineral materials.
Double-layer re-sorting structure
Improves separation accuracy with a low carryover rate, enhancing final product purity and reducing material loss.
High-durability chute system
Constructed from high-density alloy materials, the chute offers strong resistance to wear and scratching, ensuring long-term stable operation.
Low-consumption high-frequency ejection system
Ultra-high frequency solenoid valves significantly reduce material loss while maintaining precise ejection performance, even in dust-prone environments. The suspended cleaning system further supports stable operation under challenging conditions.
Advanced industry-leading optical configuration
Featuring a four-lens single-chute design with 128 ejector valves, the system delivers high-resolution detection and fast, accurate sorting performance for demanding industrial applications.
Technical Parameters
Model
K2C6
K2C6(PRO)
K2C6(APEX)
Capacity
16-26mesh
4.5-7.5t/h
16-26mesh
4.5-7.5t/h
16-26mesh
4.5-7.5t/h
26-40mesh
3.5-6.5t/h
26-40mesh
3.5-5.5 t/h
26-40mesh
3.5-6.5t/h
40-70mesh
2.5-4.5 t/h
40-70mesh
2.5-4.5 t/h
40-70mesh
2.5-4.5 t/h
70-120mesh
1.5-2.5 t/h
70-120mesh
1.5-2.5 t/h
70-120mesh
1.5-2.5 t/h
Carryover Ratio
(Bad:Good)
1:20
1:15
1:10
Sorting Accuracy
≥99%
≥99%
≥99.9%
Voltage/Frequency
380V/50HZ
380V/50HZ
380V/50HZ
Power
7.0KW
7.0KW
6.6KW
Air Pressure
0.6~0.8MPa
0.6~0.8MPa
0.6~0.8MPa
Air Consumption
≤3.6m³/min
≤3.6m³/min
≤3.6m³/min
Weight
2700KG
2700KG
2700KG
Dimension
2726*2062*2609mm
2726*2062*2609mm
2726*2062*2609mm
Sorting Cases
